54
AWM-G-2009 Engineering & Physical Data
Component Data - Cooling Only (R22)
MODEL
INDOOR UNIT AWM 25G AWM 301
OUTDOOR UNIT ALC 25C ALC 28C
INDOOR FAN
TYPE CROSS FLOW FAN CROSS FLOW FAN
QUANTITY 11
MATERIAL ACRYLO NITRILE STYRENE ACRYLO NITRILE STYRENE
DRIVE DIRECT DIRECT
DIAMETER mm/in 108 / 4.25 106 / 4.17
LENGTH mm/in 810 / 31.9 950 / 37.4
INDOOR FAN MOTOR
TYPE INDUCTION INDUCTION
QUANTITY 11
INDEX OF PROTECTION (IP) IP20 IP24
OUTDOOR FAN
TYPE PROPELLER PROPELLER
QUANTITY 11
MATERIAL
GLASS REINFORCED ACRYL
STYRENE RESIN
GLASS REINFORCED ACRYL
STYRENE RESIN
DRIVE DIRECT DIRECT
DIAMETER mm/in 457.2 / 18 457.2 / 18
OUTDOOR FAN
MOTOR
TYPE INDUCTION INDUCTION
QUANTITY 11
INDEX OF PROTECTION (IP) IP54 IP54
COMPRESSOR
TYPE ROTARY HERMETIC ROTARY HERMETIC
OIL TYPE ATMOS NM56M or SUNISO 4GDID ATMOS NM56M or SUNISO 4GDID
OIL AMOUNT cm
3
/ fl .oz. 700 / 24.6 1130 / 39.8
INDOOR COIL
TUBE
MATERIAL
SEAMLESS INNER GROOVE
COPPER
SEAMLESS INNER GROOVE
COPPER
DIAMETER mm/in 7.0 / 0.276 9.52 / 0.375
THICKNESS mm/in 0.28 / 0.011 0.35 / 0.013
FIN
MATERIAL
ALUMINIUM (HYDROPHILIC SLIT
FIN TYPE)
ALUMINIUM (HYDROPHILIC SLIT
FIN TYPE)
THICKNESS mm/in 0.11 / 0.0043 0.11 / 0.0043
FACE AREA m
2
/ft
2
0.269 / 2.900 0.291 / 3.130
ROW 22
FIN PER INCH 18 16
OUTDOOR COIL
TUBE
MATERIAL
SEAMLESS INNER GROOVE
COPPER
SEAMLESS INNER GROOVE
COPPER
DIAMETER mm/in 7.0 / 0.276 9.52 / 3/8
THICKNESS mm/in 0.28 / 0.011 0.33 / 0.013
FIN
MATERIAL RAISE LANCE ALUMINIUM (SLIT FIN)
THICKNESS mm/in 0.127 / 0.005 0.127 / 0.005
FACE AREA m
2
/ft
2
0.61 / 6.52 0.61 / 6.52
ROW 22
FIN PER INCH 18 18
AIR QUALITY
FILTER
TYPE NANO FILTER SARANET + IONIZER
QUANTITY pc 2 3 X 3
SIZE
LENGTH mm/in 351/13.8 330 / 13.0
WIDTH mm/in 386 / 15.2 317 / 12.4
THICKNESS mm/in 1.5 / 0.06 1.8 / 0.07
NEGATIVE IONIZER YES NO
CASING
INDOOR UNIT
MATERIAL HIGH IMPACT POLYSTYRENE ABS
COLOUR LIGHT GREY LIGHT GREY
OUTDOOR UNIT
MATERIAL GALVANISED MILD STEEL GALVANISED MILD STEEL
COLOUR LIGHT GREY LIGHT GREY
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
