Acson awm07f User Manual

160
Model : A5LC 20CR (3 PHASE)
No Descriptions Part No No Descriptions Part No
1 ASSY,PAN BASE (5SL20C/CR) R50014078281 15 ASSY VALVE COVER (SL20C/CR) R50124072885
3 BRACKET MOTOR (SL20C/CR) R01014070601
18 ASSY PARTITION (SL20C/CR) R50064072871
8 COMPRESSOR, 5KS205PAB01 MAT R04019029246
9 PANEL FRONT/LEFT (SL20C/CR) R01014070597
10 PANEL SERVICE (SL20C/CR) R01014070598
12 PANEL TOP (SL20C/25C/28C/CR) R01014070596 CLAMP, CAPACITOR 126.0mm R07054028872
VALVE, REV 4 WAY SHF-7H-
34U(RK) SHANHUA
R05019016937
PHASE PROTECTOR, PP1.03 NO
SENSOR EXPORT
R04089018834
CAPACITOR, CMPSR 50uF/450VAC
Shizuki
R04029026779
ASSY TERMINAL PANEL
(SL20C/25C/28C/CR)
R50014072877
PANEL TERMINAL COVER
(SL20C/25C/28C/CR)
R01014070838
CAPACITOR, CMPSR
3.5uF/450V(TAB250)Shizu
R04029026759
ASSY,VALVE 3-WAY(1/2")JB48420-
1MA(R410A)
R50059023335
ASSY,VALVE 2-WAY(1/4")JA28493-
2MA(R410A)
R50059023334
16 ASSY,CAPILLARY TUBE (5SL20CR) R50024081904
17
ASSY,TUBING 4-WAY VALVE
(5SL20CR)
R50024080655
14
PLASTIC,HANDLE
SL07C/09C/10C/15C/CR
R12014057948
6
ASSY,VALVE BRACKET
(5SL20C/CR)
R50014078280
11
ASSY CONTROL PANEL (5SL20CR
3PH)
R50044092275
13
ASSY FRONT GRILLE
(SL20C/25C/28C/CR)
R50124072880
R03019023393
7 PANEL RIGHT BACK (SL20C/CR) R01014070599
Parts Not In The Diagram
2
ASSY,OUTDOOR COIL (5SL20C/CR
-
2RX28TH)
R50024075143
4
MOTOR,YDK64-6C/MSL25C-501-
WL
R03039023391
5
FAN PROPELLER, ¥460 0Z40700
SUNWILL CHIN
