AWM-J-2010 Performance Data
Model: AWM20J - ALC20C
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
424
16°C
21°C 5.25 3.57 1.41 5.07 3.47 1.52 4.88 3.38 1.65 4.68 3.28 1.79 4.30 3.06 1.94 3.97 2.87 2.14
24°C 5.26 4.27 1.41 5.07 4.17 1.52 4.88 4.08 1.65 4.69 3.98 1.79 4.31 3.71 1.94 3.98 3.50 2.14
27°C 5.30 4.84 1.41 5.12 4.73 1.52 4.94 4.62 1.65 4.76 4.50 1.79 4.39 4.19 1.94 4.08 3.94 2.14
30°C 5.46 5.46 1.41 5.31 5.31 1.53 5.15 5.15 1.66 4.98 4.98 1.80 4.62 4.62 1.96 4.32 4.32 2.16
19°C
24°C 5.79 3.33 1.43 5.59 3.25 1.55 5.38 3.16 1.67 5.17 3.07 1.82 4.75 2.86 1.97 4.39 2.69 2.17
27°C 5.80 3.81 1.43 5.59 3.73 1.55 5.39 3.64 1.68 5.18 3.55 1.82 4.76 3.32 1.97 4.40 3.15 2.17
30°C 5.81 4.70 1.43 5.60 4.60 1.55 5.41 4.50 1.68 5.20 4.39 1.82 4.79 4.11 1.97 4.44 3.89 2.18
33°C 5.87 5.87 1.43 5.68 5.68 1.55 5.50 5.50 1.68 5.31 5.31 1.83 4.91 4.91 1.98 4.59 4.59 2.19
22°C
27°C 6.37 3.26 1.45 6.15 3.18 1.58 5.93 3.10 1.71 5.70 3.02 1.85 5.24 2.81 2.01 4.85 2.65 2.21
30°C 6.37 3.97 1.45 6.15 3.89 1.58 5.93 3.80 1.71 5.70 3.71 1.85 5.24 3.47 2.01 4.85 3.29 2.21
33°C 6.38 4.64 1.45 6.16 4.55 1.58 5.93 4.46 1.71 5.70 4.37 1.85 5.25 4.10 2.01 4.86 3.90 2.22
36°C 6.40 5.26 1.46 6.19 5.16 1.58 5.97 5.05 1.71 5.76 4.94 1.86 5.31 4.63 2.01 4.93 4.39 2.22
478
16°C
21°C 5.46 3.72 1.42 5.27 3.62 1.53 5.07 3.53 1.66 4.86 3.43 1.80 4.46 3.19 1.95 4.11 3.00 2.15
24°C 5.48 4.52 1.42 5.28 4.41 1.53 5.09 4.30 1.66 4.88 4.20 1.80 4.48 3.91 1.96 4.14 3.69 2.16
27°C 5.55 5.13 1.42 5.36 5.01 1.54 5.17 4.88 1.67 4.99 4.74 1.81 4.61 4.40 1.96 4.29 4.11 2.17
30°C 5.78 5.78 1.43 5.61 5.61 1.55 5.44 5.44 1.68 5.26 5.26 1.83 4.88 4.88 1.98 4.56 4.56 2.19
19°C
24°C 6.02 3.52 1.44 5.80 3.43 1.56 5.59 3.34 1.69 5.36 3.25 1.83 4.92 3.03 1.99 4.55 2.85 2.19
27°C 6.03 4.05 1.44 5.81 3.96 1.56 5.60 3.87 1.69 5.37 3.78 1.83 4.94 3.54 1.99 4.56 3.35 2.19
30°C 6.06 5.00 1.44 5.85 4.89 1.56 5.64 4.78 1.69 5.42 4.67 1.84 4.99 4.36 1.99 4.63 4.12 2.20
33°C 6.16 6.16 1.45 5.97 5.97 1.57 5.78 5.78 1.70 5.59 5.59 1.85 5.18 5.18 2.01 4.84 4.84 2.22
22°C
27°C 6.61 3.45 1.47 6.38 3.36 1.59 6.14 3.28 1.72 5.90 3.19 1.87 5.42 2.98 2.03 5.01 2.81 2.23
30°C 6.62 4.23 1.47 6.39 4.14 1.59 6.15 4.05 1.72 5.91 3.95 1.87 5.43 3.70 2.03 5.02 3.51 2.23
33°C 6.63 4.95 1.47 6.40 4.86 1.59 6.17 4.76 1.73 5.93 4.66 1.87 5.45 4.37 2.03 5.05 4.15 2.24
36°C 6.67 5.60 1.47 6.46 5.49 1.60 6.23 5.38 1.73 6.01 5.26 1.88 5.54 4.92 2.04 5.17 4.64 2.25
536
16°C
21°C 5.67 3.88 1.43 5.46 3.78 1.55 5.25 3.68 1.67 5.03 3.58 1.82 4.61 3.33 1.97 4.25 3.14 2.17
24°C 5.70 4.72 1.43 5.49 4.60 1.55 5.28 4.49 1.68 5.07 4.37 1.82 4.65 4.08 1.97 4.30 3.85 2.17
27°C 5.79 5.41 1.44 5.60 5.27 1.55 5.41 5.12 1.68 5.21 4.96 1.83 4.82 4.59 1.98 4.49 4.29 2.19
30°C 6.08 6.08 1.45 5.90 5.90 1.57 5.72 5.72 1.70 5.53 5.53 1.85 5.12 5.12 2.01 4.78 4.78 2.22
19°C
24°C 6.24 3.72 1.45 6.01 3.63 1.57 5.78 3.54 1.70 5.55 3.44 1.85 5.09 3.21 2.00 4.70 3.03 2.21
27°C 6.25 4.31 1.45 6.03 4.21 1.57 5.80 4.11 1.71 5.57 4.01 1.85 5.11 3.75 2.01 4.73 3.55 2.21
30°C 6.31 5.30 1.46 6.08 5.19 1.58 5.86 5.07 1.71 5.64 4.94 1.85 5.19 4.61 2.01 4.82 4.35 2.22
33°C 6.44 6.44 1.46 6.25 6.25 1.59 6.06 6.06 1.72 5.86 5.86 1.87 5.43 5.43 2.03 5.08 5.08 2.24
22°C
27°C 6.84 3.64 1.48 6.60 3.56 1.60 6.35 3.47 1.74 6.10 3.38 1.89 5.60 3.16 2.04 5.17 2.98 2.25
30°C 6.86 4.49 1.48 6.61 4.41 1.60 6.36 4.31 1.74 6.11 4.21 1.89 5.61 3.94 2.05 5.19 3.74 2.25
33°C 6.88 5.26 1.48 6.64 5.17 1.61 6.40 5.06 1.74 6.15 4.95 1.89 5.66 4.64 2.05 5.24 4.40 2.26
36°C 6.94 5.94 1.49 6.72 5.83 1.61 6.49 5.71 1.75 6.26 5.56 1.90 5.78 5.19 2.06 5.39 4.89 2.27
Remark:
AFR: Air fl ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling Capacity (kW)
SHC: Sensible Heat Capacity (kW)
PI: Power Input
Notes:
1. Ratings shown are gross capacities which do not include a deduction for indoor fan motor heat.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 0 °C to 46°C without pressure trip.
