AWM-J-2010 Electrical Data
Electrical Data
Electrical Data - Cooling Only (R22)
MODEL
INDOOR UNIT AWM09J AWM15J
OUTDOOR UNIT ALC09C ALC15C
INDOOR MOTOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 220 - 240 / 1/ 50
RATED INPUT POWER W 31 40
RATED RUNNING CURRENT A 0.18 0.20
MOTOR OUTPUT W 18 18
POLES 44
OUTDOOR MOTOR
INSULATION GRADE CLASS B CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 220 - 240 / 1/ 50
RATED INPUT POWER W 45 59
RATED RUNNING CURRENT A 0.20 0.26
MOTOR OUTPUT W 18 24
POLES 66
COMPRESSOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 220 - 240 / 1/ 50
CAPACITOR μF 30.0 30.0
RATED INPUT POWER W 849 1077
RATED RUNNING CURRENT A 3.70 4.90
LOCKED ROTOR AMP. A 20 23
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.
Electrical Data - Heat Pump (R22)
MODEL
INDOOR UNIT AWM09JR AWM15JR
OUTDOOR UNIT ALC09CR ALC15CR
INDOOR MOTOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 220 - 240 / 1/ 50
RATED INPUT POWER W 31 40
RATED RUNNING CURRENT A 0.18 0.20
MOTOR OUTPUT W 18 18
POLES 44
OUTDOOR MOTOR
INSULATION GRADE CLASS B CLASS B
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 220 - 240 / 1/ 50
RATED INPUT POWER W 45 59
RATED RUNNING CURRENT A 0.20 0.26
MOTOR OUTPUT W 18 24
POLES 66
COMPRESSOR
INSULATION GRADE CLASS E CLASS E
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50 220 - 240 / 1/ 50
CAPACITOR μF 30.0 30.0
RATED INPUT POWER (COOLING) W 849 1093
RATED INPUT POWER (HEATING) W 674 967
RATED RUNNING CURRENT (COOLING) A 3.70 5.00
RATED RUNNING CURRENT (HEATING) A 3.00 4.50
LOCKED ROTOR AMP. A 20 23
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.

Acson AWM15J Specifications

General

Brand	Acson
Model	AWM15J
Category	Air Conditioner
Language	English
