Acson C Series - Page 5

English
1-3
Dimension
Model
ABCDEFGHI JKL
CC28CW 987 997 920 959 296 36 824 869 131 339 136 367
CC38CW 1292 1297 1225 1264 316 36 824 1174 119 401 147 394
Dimension
Model
MNO PQR S TUV
CC28CW 97 600 521 121 213 410 91 137 87 167
CC38CW 97 638 559 186 233 563 156 148 97 149
16
50
31 (CC28CW)
51 (CC38CW)
15
25
R
H
KLM
G
D
371
40
F
C
B
A
E
P
S
15 15
15
N
O
25
U
T
V
22
160
Q
IJI
All dimensions are in mm
All dimensions are in mm
25
31 (CC28CW)
160
22
V
U
T
C
O
15
15
S
15
P
51 (CC38CW)
ML
E
B
A
F
K
D
G
371 40
15
16
50
25
R
H
Q
N
IJI
LEFT PIPING
RIGHT PIPING
WATER OUTLET
WATER INLET
WATER OUTLET WATER INLET
