Step 1: Install the Gang Box
Before installation, note that the gang box must be installed with either of the following
orientation:
Screw Holes from Left to Right
Screw Holes from Right to Left
4” Round
4” Octagon
1. Remove a knockout on the gang box to route the network cable.
2. Route the network cable along the surface or inside the surface and into the gang box.
3. Attach the gang box on the surface or inside the surface according to the recommended
orientation above.
