CAUTION: The camera itself is waterproof, however take note that the cable connections
are not. If the cable connections will be exposed outdoors, make sure to shield or
adapt proper waterproofing methods. See Waterproof the Cable Connections
on page 20.
DISCLAIMER: ACTi will not be responsible for camera damage caused by water entering the
cable connections.
3. Mount the camera
1. Align the gap on the camera to the tab inside the mounting solution and insert the camera
through the mounting tube.
2. Attach the screws included in the camera package to secure the camera.
4. Attach the Ferrite Cores and Connect the Cables
Perform behind the wall cable connections as needed. See the succeeding chapters for
detailed information.
