4886 SPARE PARTS-VERTICAL ARM
Page 2 of 6 – 03/2008
ref description description specification qty
ST8862-A Ens. cylindre cylinder assembly 1
ST8862-B Ens. Corps cylindre locking cylinder assembly 1
ST8862-C Ens. Plaque de fermeture locking plate assembly 1
ST8862-D Poignee complete hand-control valve assembly 1
ST8862-E Bras vertical complet complete vertical arm 1
ST886201 Tete de montage mounting head 4＃ 1
ST886202 Galet roller M13X13 1
ST886203 Goupille pin M6X24 1
ST886204 Vis screw M10X25 8.8 1
ST886205 Rondelle de pression pressing washer ∅ 34X∅ 11X8 1
ST886206 Rondelle amortisseur shock absorber S36 1
ST886207 Vis sans tete Screw M12X12 2
ST886208 Ressort spring 2.0X9X95 2
ST886209 Vis screw M4X16 4
ST886210 Vis screw M6X10 2
ST886211 Raccord union G1/8" 8 1
ST886212 Poignee handle 1
ST886213 Butee stop-up M20 1
ST886214 Vis screw M10X85 1
ST886215 Vis sans tete Screw M12X16 2
ST886216 Pastille plastique plastic protection cover 1
ST886217 Insert plastique plastic protection cover 1
ST886218 Joint o-ring ∅ 10X2 4
ST886219 Rondelle flat washer 4 4
ST886220 Ecrou frein locknut M10 1
ST886221 Corps de cylindre cylinder body 1
ST886222 Vis screw M6X35 2
ST886223 Joint y-ring ∅ 65X8 1
ST886224 Couvercle de cylindre cylinder housing 1
ST886225 Lame de position positioning blade 1
ST886226 Rondelle elastique elastic washer 10 1
ST886227 Ressort spring ∅ 640X3.0X50 1
