4886 SPARE PARTS-TURNTABLE
Page 4 of 6 – 03/2008
ref description description specification qty
ST8864-A Plateau complet turntable assembly 1
ST8864-B Joint tournant complet rotate union complete 1
ST8864-C Verin complet cylinder assembly 2
ST886401A Plateau turntable 1
ST886402 Rivet rivet 3X8 4
ST886403 Vernier scale 2
ST886404 Vis screw 12X30 1
ST886405 Bouchon turntable cap 1
ST886406 Goupille pin ∅ 4X16 4
ST886407 Clavette disk key 10X45 1
ST886408 Protection de glissiere clamp cover 4
ST886409 Mors clamp 4＃ 4
ST886410 Glissiere slide 4
ST886411 Entretoise mobile werable washer 4
ST886412 Plaque de glissiere slide plate 2
ST886413 Rondelle flat washer 12 12
ST886414 Rondelle elastique elastic washer 12 8
ST886415 Vis screw M12X35 4
ST886416 Vis screw M12X83 4
ST886417 Plaque tournante turntable 1
ST886418 Entretoise spacer 4
ST886419A Entretoise de connection connecting plate 4
ST886420 Bague seeger seeger ring 65＃ 1
ST886421 Bague seeger seeger ring 12＃ 4
ST886422 Support verin cylinder bracket 2
ST886423 Ecrou frein locknut M8 16
ST886424 Plaque arriere de verin cylinder rear housing 2
ST886425 Tige de verin Shaft M8 8
ST886426 Corps de verin cylinder body ∅ 80 2
ST886427 Plaque avant de verin cylinder front housing 2
ST886428 Axe de verin shaft for cylinder 2
ST886429 Raccord union ∅ 8 2
ST886430 Vis screw M3X6 4
