S001964 10ft Trampoline
AssemblyInstructions(cont)
Step 2
Attachthe6xLegExtensions(5)tothe3xLegBases(4)andsecurethemintoplaceusing6xBolts
(10).
Takethe3setsoflegsandinsertthemintothebaseoftheT-Joints(9)ontheframeandsecurethem
intoplaceusing6xBolts(10).
Note: The bolts should be placed on the inside of the frame
4
4
5
5
10
10
9
3
