4
ASSEMBLY AND OPERTATING INSTRUCTIONS
Water Supply (Cold Water Only):
• Do not draw non-water liquids through the unit. For
use with cold water supply only.
• Water hose must be at least a 1/2 inch diameter.
• Flow rate of water supply must not fall below 2
GPM (gallons per minute).
• Flow rate can be determined by running the water
for one minute into an empty 5-gallon container.
• The water supply temperature must not exceed
104°F (40°C).
CAUTION
• Never use the pressure washer to draw
in water contaminated with solvents (e.g.
paint thinners, gasoline, oil, etc.).
• Dirt in the feed water will damage the unit.
To avoid this risk, we recommend checking
the water lter (located inside the water
inlet; to clean it out see Maintenance sec-
tion on page 11).
• Always prevent debris from being drawn
into the unit by using a clean water source
and an accessory water lter if required.
CAUTION
To prolong the life of the unit, it is recom-
mended to rest the unit 5 minutes after
every 30 minutes of use.
Assembly Time: 2 minutes / Tools Required: None
Surface Preparation
Before starting any cleaning task, it is important to inspect the area for objects which could create a hazard.
Remove from the workarea which could be tripped over, such as toys or outdoor furniture. Ensure that all
doors and windows are closed tight.
Step 1
Make sure that the ON/OFF switch is in the
“OFF” position.
Step 3
Insert the wand into spray gun, and twist 1/4 turn until rectangular tab appears.
Step 2
Separate the adaptor and quick-connect coupling.
Attach inlet adaptor to the machine’s inlet and attach
the quick-connect coupling onto the garden hose.
Fig. 1
Fig. 3
Fig. 2
