Fig.3
Fig.2Fig.1
Make sure that the ON/OFF switch is in the
“OFF” position.
•
•
•
•
•
Separate the adaptor and quick-connect
coupling. Attach inlet adaptor to the machine’s
inlet and attach the quick-connect coupling
onto the garden hose.
Insert the wand into spray gun, and twist 1/4 turn until rectangular tab appears.
Do not draw non-water liquids through the unit. For
use
with cold water supply only.
Water hose
must be at least a 1/2” in diameter.
Flow
rate of water supply must not fall below 2 GPM
(gallons
per minute).
Flow
rate can be determined by running the water
for
one minute into an empty 5-gallon container.
The
water supply temperature must not exceed
104°F (40°C
).
Step 1 Step 2
Step
3
Water Supply (cold Water Only)
Caution
• Never use the pressure washer to draw
in water contaminated with solvents
(e.g. paint thinners, gasoline, oil, etc.).
• Dirt in the feed water will damage the
unit. To avoid this risk, we recommend
checking the water filter (located inside
the water inlet; to clean it out see
Maintenance section).
• Always prevent debris from being
drawn into the unit by using a clean
water source and an accessory water
filter if required.
Caution
To prolong the life of the unit, it is
recommended to rest the unit 5 minutes
after every 30 minutes of use.
ASSEMBLY AND OPERATING INSTRUCTIONS
5
