Actreg ADA SERIES User Manual

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
13
10. RECOMMENDED SPARE PARTS
The spare parts kit of the ADA & ASR ACTREG actuator is made up of the following parts:
Nº Quantity Name
5 1 Soft Pinion Washer
6 2 Slide Piston
8 1 Metallic Pinion Washer
10 1 Upper Pinion Bearing
24 2 Rubber Plug
25 2 Slide Guide
26 1 Lower Pinion Bearing
109 2 Piston’s O-ring
110 1 Lower Pinion’s O-ring
111 1 Upper Pinion’s O-ring
118 2 Cap’s O-ring
119 2 O-ring
471 1 Slip Washer
