Actreg ADA SERIES User Manual

PNEUMATIC ACTUATORS
ASSEMBLY & MAINTENANCE PROCEDURES
Ref. Doc. MMMACTREGDRE English Rev.2 – January 2012
4
1. APPLICABLE RANGE
The Pneumatic Actuators ACTREG use a rack and pinion sliding system that creates a linear torque
with a quarter turn operation. The range is the following:
ADA-10
ADA-20
ADA-40
ADA-80
ADA-130
ADA-200
ADA-300
ADA-500
ADA-850
ADA-1200
ADA-1750
ADA-2100
ADA-2500
ADA-4000
SPRING COMBINATIONS
ASR-20 S04 S06 S08
ASR-40 S04 S06 S08 S10 S12 S14
ASR-80 S04 S06 S08 S10 S12 S14
ASR-130 S06 S08 S10 S12 S14
ASR-200 S06 S08 S10 S12 S14
ASR-300 S06 S08 S10 S12 S14
ASR-500 S06 S08 S10 S12 S14
ASR-850 S06 S08 S10 S12 S14
ASR-1200 S06 S08 S10 S12 S14
ASR-1750 S06 S08 S10 S12 S14
ASR-2100 S06 S08 S10 S12 S14
ASR-2500 S06 S08 S10 S12 S14
ASR-4000 S06 S08 S10 S12 S14
SERIE ADA
Double Acting
SERIE ASR
Spring Return
