No. Amps. Circuits Protected No. Amps. Circuits Protected
No. Amps. No. Amps. Circuits ProtectedCircuits Protected
1
2
3
4
5
6
7
8
9
10
11
12
13
20 A
30 A
20 A
15 A
15 A
20 A
20 A
20 A
40 A
30 A
30 A
40 A
Spare Fuse
Spare Fuse
Right Headlight
ACG S
Hazard
Not used
Stop
Left Headlight
Radio
Power Window Motor
Rear A/C
Rear Defroster
Back Up, ACC
14
15
16
17
18
19
20
21
22
23
24
40 A
40 A
30 A
7.5 A
10 A
15 A
120 A
30 A
7.5 A
50 A
20 A
Power Seat
Heater Motor
Cooling Fan
Spare Fuse
Spare Fuse
Spare Fuse
Battery
Condenser Fan
MG Clutch
IGI Main
Fog Lights
1
2
3
4
5
20 A
40 A
30 A
20 A
20 A
6
7
8
9
10
15 A
15 A
15 A
7.5 A
20 A
ETC
IG Coil
LAF
FI-Back-up
P/W DR
Rear Entertainment System
VSA F/S Relay
VSA Motor
4WD
Rear Accessory Socket
Fuse Locations
Taking Care of the Unexpected
279
PRIMARY UNDER-HOOD FUSE BOX
SECONDARY UNDER-HOOD FUSE BOX
