CONTINUED
Remove the electrical connector
from the bulb by pushing on the
tab and pulling the connector
down.
Remove the bulb by turning it one-
quarter turn counterclockwise.
Remove the left or right side
engine compartment cover from
thesideyouareworkingonby
carefully pulling the cover out (see
page ).
Ifyouarereplacingthebulbon
the driver’s side, remove the
battery cover (see page ).
Your vehicle has halogen high beam
headlight bulbs which are also used
for the daytime running light.
Handle it by its base and protect the
glass from contact with your skin or
hard objects. If you touch the glass,
clean it with denatured alcohol and a
clean cloth.
2.
3.
1.
451
485
Lights
Replacing a Headlight/Daytime
Running Light Bulb
Maintenance
463
BULB
CONNECTOR
Halogen bulbs get very hot when lit. Oil,
perspiration, or a scratch on the glass
can cause the bulb to overheat and
shatter.
０９／０４／０２ １９：３８：１１ ３１ＳＪＡ６５０ ０４６８
