5. Insert the new bulb into the hole,
and turn it one-quarter turn
clockwise to lock it in place.
6. Push the electrical connector onto
the new bulb.
7. Turn on the headlights to test the
new bulb.
Replacing Front Turn Signal/
Parking and Side Marker Light
Bulbs
1. Open the hood.
2. Remove the front bulkhead cover
(see page 392).
3. Remove the socket by turning it
one-quarter turn counterclockwise.
4. Pull the bulb straight out of its
socket.
5. Push the new bulb straight into
the socket until it bottoms.
6. Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
7. Turn on the lights to make sure
the new bulb is working.
FRONT TURN SIGNAL LIGHT
BULB
SOCKET
BULB
PARKING LIGHT
SOCKET
Lights
404
