3.1 JET - CONTROLS
To make the operation of the suite more understandable, we will go into the explanation of
the Jet (Bus) version controls, the more complete of the two Players by dividing them into
sections.
1-DYNAMIC:
Used to set the parameters of the dynamic eq, it includes:
• Attack:
Sets the compressor’s attack time, ranging from 0.1 mS (fast) to 40 mS (slow).
• Release:
Sets the compressor’s release time, ranging from 0.5 S (fast) to 1.2 S (slow); plus,
two even slower times were added, called A1 and A2.
• Sensitivity:
This determines the amount of the eq effect that is applied to the signal. Ran-
ging from 0% to 100%.
• Threshold:
This sets the signal level where the dynamic eq starts working. Ranging from
-48 to 0 dB. When the audio breaches the threshold, boosts and cuts are applied, thus
compressing or expanding the dynamic range of the frequencies concerned.
2-SIDECHAIN:
Used to modify the control signal, it includes:
• ON button (Ext SC):
To select if the control signal is taken from channels 1-2 or 3-4.
NOTE:
Sidechaining is a process that allows you to feed a plug-in such as a compressor or a gate
with an external audio signal which will then trigger a key element of the process.
Activating the external sidechain button each compressor may be use on an external signal,
instead of the main input, to control the amount of dynamic equalization or audio compres-
sion.
1) Internal Sidechain key signal is the same as the source signal and normally is processing
with a filter (channels n.1 & 2)
2) External Sidechain the key signal is a signal coming from a different channel or bus and
the plug-in should be set to receive and process this key signal with the plug-in’s input 3 and
4. (channels n.3 & 4).
• External sidechain knob:
Changes the gain of the control signal by +/- 24 Db.
NOTE: For an immediate understanding, the signal flow of the INTERNAL and EXTERNAL
sidechain* is shown below.
• ON:
Enable the gain control described below.
• Internal sidechain knob:
Change the gain of the control signal by +/- 24.
• Stereo link:
Makes the control signal mono (100%).
3-STATIC EQ:
Used to modify the gain of the eq at the begin of the chain.
• ON:
Enables the static eq.
• Gain LF:
Controls the gain of the Low Frequency band ranging approx. -13/+13 dB.
• GAIN HF:
Controls the gain of the Low Frequency band ranging approx. -13/+13 dB.
