ACV 50 - Page 17

EN • 17
ENGLISHFRANCAISNEDERLANDSESPAÑOLITALIANODEUTSCH
664Y3000.A
INSTALLATION
AV MPK ZU AUF
0 24V A B VF VE
ZMC1
N
Y1
Y2
PhPE
NN
21BA
1 2 3 4 5 6 7 8 9 10 11 12 13 1 2 6543
PE
Ph
N
1 2 3 4 5 6 7 8 9 10 11 12 13
B
A
Factory
setting
typical
setting Description
00 : Heating mode “OFF”
01 : Heating mode “ON”
Setting T° for the heating water
(adjustable between 30 and 85°C).
T° min. for the heating water
(adjustable between 15 and 60°C).
10800036: Interface address “0”
= 7
= 6
= 5
= 4
= 3
= 2
= 1
= 0
To be wired in accordance with the applicable regulations.
