TECHNICAL CHARACTERISTICS
* Designations and references (between brackets) are provided as information only. Please refer to the latest ACV Price list for more information and the correct references.
Boiler Models
Connection
type
Material /
Ø (mm)
Components *
Terminals Pipes Extensions Bends
Measurement and
condensate recovery
Accessories Adapters
WaterMaster 70-85-120
C13
C33
PP - Galva Ø
100/150
• Roof Terminal
(537D6300)
• Wall terminal
kit (537D6301)
Lengths :
• 250 mm
(537D6302)
• 500 mm
(537D6303)
• 1000 mm
(537D6304)
• 2000 mm
(537D6517)
Sliding extension,
straight
(+ 50 to
130 mm)
(537D6305)
• 43° - 45°
(537D6306)
• 87° - 90°
(537D6307)
• Measuring Tube
( 537D6308)
• Measuring T-piece
with inspection
(537D6310)
• Weather Slate Steep
25°-45° (537D6209)
• Bracket Ø 150 mm
(537D6210)
• Weather Slate, Flat
roof (Ø 430 mm)
(537D6208)
Concentric to parallel
Ø 100/150 mm - 2 x Ø
100 mm (537D6207)
WaterMaster 70-85-120
B23P
C53
SST
Ø 150
• Roof Terminal ,
ue Ø 150
(537D6211)
• Wall terminal
kit , ue, Ø 150
(537D6212)
• Wall terminal
kit, air,
Ø 100
(537D6213)
Lengths, flue, Ø 150 :
• 250 mm
(537D6214)
• 500 mm
(537D6215)
• 1000 mm
(537D6216)
Length, air, PVC Ø
100 :
• 500 mm
(537D6217)
Sliding extension,
flue, Ø 150
(537D6218)
• Flue, Ø 150, 45°
(537D6219)
• Flue, Ø 150, 90°
(537D6220)
• Air, Ø 100, 45°
(537D6221)
• Air, Ø 100, 90°
(537D6222)
Element for measure-
ment and recovery of
condensates, ue,
Ø 150 (537D6223)
• Weather Slate Steep
25°-45° (537D6209)
• Bracket Ø 150 mm
(537D6210)
• Weather Slate, Flat
roof (Ø 430 mm)
(537D6208)
• Expander Ø 100 -
Ø 150 mm mandatory
(537D6293)
• Concentric to parallel
adapter Ø 100/150
mm - 2 x Ø 100 mm
(537D6207)
• Adapter Ø 80 - Ø 100
mm, air (537D6172)
