WaterMaster 25 - 35 - 45 - 70 - 85 - 120 : A1006482 - 664Y7300 • D
TECHNICAL CHARACTERISTICS
* Designations and references (between brackets) are provided as information only. Please refer to the latest ACV Price list for more information and the correct references.
Boiler Models
Connection
type
Material /
Ø (mm)
Components *
Terminals Pipes Extensions Bends
Measurement and
condensate recovery
Accessories
Adapters
WaterMaster 70-85-120
C13
C33
SST - SST
Ø 100/150
• Roof Terminal,
(537D6197)
• Wall terminal
(537D6198)
Lengths :
• 250 mm
(537D6199)
• 500 mm (537D6200)
• 1000 mm
(537D6201)
Sliding extension
(280 to 395 mm)
(537D6202)
• 43° - 45°
(537D6203)
• 87° - 90°
(537D6204)
Element for measure-
ment and recovery
of condensates, ue,
(537D6226)
• Weather Slate Steep
25°-45° (537D6209)
• Bracket Ø 150 mm
(537D6210)
• Weather Slate, Flat
roof (Ø 430 mm)
(537D6208)
Concentric to parallel
adapter Ø 100/150 mm - 2 x
Ø 100 mm (537D6207)
