MEASUREMENT FOUNDATION
6
INSTRUMENT SINSTRUMENT S
WallScanner 120 Prof
Operation
INSERTING/REPLACING THE BATTERY
Use only 9Vbattery. Insert the battery into the battery compartment (13) in accordance with the symbols in the battery com-
partment. Remove the batteries if the unit will not be used for a long period. The battery can be corroded or discharged over
long periods.
SWITCHING ON AND OFF
Protect the measuring tool against moisture and direct sun irradiation. Before switching the measuring tool on, make sure that
the sensor area 12 is dry. If required, wipe the measuring tool dry using a cloth.
If the measuring tool was subject to an extreme temperature change, allow it to the adjust to the ambient temperature before
switching on. Press ON/OFF button to switch on the instrument. After a short test the detector is ready for operation.
The measuring tool automatically enter the function mode of metal detection.
SCANNING
Put the tool on the surface of the object. Choose the correct operating mode and always move the tool in a straight line
(as shown on the picture).
