Ada MP-1-CHANNEL - Safe High Voltage Discharge

Page 7
otherscrewtowardsthecenterofthebackpanel.Thisscrewalsohasalock
washerandservesasthegroundconnectionfortheenclosure.



3. Thebottompanelcanbeslidoff.Notethatthebottompanelhasacutoutforthe
INPUTandOUTPUTjacks,andmust
bere‐installedthesamewaywiththiscutout
aroundthejacks.
4. Thevacuumtubescanbepulledoutoftheirsocketsand,whenreplaced,besure
thateachisfullyseatedinthesocketandstraight.
5. Anotherwaytodischargethehighvoltageistoplacea
metal‐tippedscrewdriver
betweenthetwopointsontheprintedcircuitboardasshowninthepicturebelow.
