Assembly and Wiring
The board comes with all surface-mount components pre-soldered. The included header strip can be soldered on for
convenient use on a breadboard or with 0.1" connectors. However, for applications subject to extreme accelerations,
shock or vibration, locking connectors or direct soldering is advised.
Assembly:
Position the Header:
Cut the header to size if necessary. Then plug the
header - long pins down - into a breadboard to stabilize
it for soldering.
