Sub10 MK2 Manual / english
12 . Technical Data
1 = long term IEC 265-8-Wrms / 10 min
2 = nominal IEC 265-8 = Peak Power 5 µsec
Sub10 MK2
Subwoofer 260 mm / 10“
Voice coil ø 50 mm / 2“
Woofer material coated paper
Built-in amplifiers 1
Subwoofer channel
1/2
200 W / 300 W
Frequency response 25 Hz - 150 kHz
THD >60 Hz ≤ 1%
Max. peak ≥ 113 dB
Crossover frequency 50 - 150 Hz
Inputs XLR / RCA
Input impedance 10 kΩ
Weight 21 kg / 46.3 lb.
Height x Width x Depth 560 x 300 x 400 mm / 22“ x 12“ x 15.5“
Warranty 5 years
Operating temperature 0° C to 40° C (32° F to 104° F)
Storage temperature -30° C to 70° C (-22° F to 167° F)
Humidity Max. 90 % not condensing
