15
Sub8 Manual / english
12 . Technical Data
1 = long term IEC 265-8-Wrms / 10 min
2 = nominal IEC 265-8 = Peak Power 5 µsec
Sub8
Subwoofer 210 mm / 8.5“
Voice coil ø 38 mm / 1.5“
Woofer material coated paper
Built-in amplifiers 1
Subwoofer channel
1/2
160 W / 240 W
Frequency response 28 Hz - 150 kHz
THD >60 Hz ≤ 1%
Max. peak ≥ 110 dB
Crossover frequency 50 - 150 Hz
Inputs XLR / RCA
Input impedance 10 kΩ
Weight 12 kg / 26.5 lb.
Height x Width x Depth 410 x 260 x 380 mm / 16“ x 10“ x 15“
Warranty 5 years
Operating temperature 0° C to 40° C (32° F to 104° F)
Storage temperature -30° C to 70° C (-22° F to 167° F)
Humidity Max. 90 % not condensing
