T SERIES MANUAL [ENGLISH]
4. REAR-PANEL FEATURES
[1] BASS-REFLEX PORT – The bass-reflex port works together with the monitor’s woofer
to produce flat and extended bass response.
[2] HF SWITCH – Use this switch to boost or cut the monitor’s high-frequency response
by 2 dB. The “0” setting maintains flat response.
[3] LF SWITCH – Use this switch to boost or cut the monitor’s low-frequency response
by 2 dB. The “0” setting maintains flat response.
[4] LEVEL KNOB – Turn this knob clockwise to increase the monitor’s volume, or
counterclockwise to decrease its volume. The “0 dB” setting will be optimal in
most situations.
[5] BAL. IN CONNECTOR – Use this XLR connector to input balanced audio with nominal
+4 dBu level.
[6] UNBAL. IN CONNECTOR – Use this RCA connector to input unbalanced audio with
nominal -10 dBV level.
[7] +4 dBu/-10 dBV SWITCH – Set this switch to the “+4 dBu” position when inputting
au dio using the Bal. in [XLR] connector. Set the switch to the “-10 dBV” position
when inputting audio using the Unbal. in [RCA] connector.
[8] POWER SWITCH – Set this switch to the ON position to apply power to the monitor.
An associated green LED will light when the monitor is turned on.
[9] POWER CONNECTOR – Use this standard three-prong IEC AC power receptacle to
connect the detachable AC cord to the monitor.

Adam T5V Specifications

General

Frequency range	45 - 25000 Hz
Noise level (high gain)	106 dB
Line-out Total Harmonic Distortion (THD)	0.5 %
Line-in Total Harmonic Distortion plus Noise (THD+N) (1kHz)	- %
RMS rated power	70 W
Woofer diameter (imperial)	5 \
Tweeter diameter (imperial)	1.9 \
Built-in display	-
Line inputs (RCA)	1
Product color	Black
Cables included	AC
Power consumption (max)	132 W

Weight and Dimensions

Depth	297 mm
Width	179 mm
Height	298 mm
Weight	5700 g
