10
MANUAL BACKUP
(CONTINUED)
1) Our first step requires this assembled tool. It attaches to the end of the PIVOT motor of the LINK. Insert the split end
socket into this opening and fit it onto the end of the pivot motor. Turn the handle of the tool CLOCKWISE to make the
LINK pivot into the vehicle. Turn until the LINK is at a 90 degree angle with the vehicle. It will likely be touching the door
of the vehicle.
2) Next, we need to move the TRAVEL motor until the seat is almost touching the steering wheel. To do this, use the ¼ inch
hex tool (ratchet) in the outer hole and turn CLOCKWISE.
Check periodically how close you are to the steering wheel as
you do not want to force the seat and risk it getting jammed. 3) Then, use the lever on the side of the seat (or button if
equipped with power recline) to tilt the seatback as far forward as possible. This will give you more space to clear the
steering wheel.
