Control Panel
Long press [ ] knob (3) to turn on the unit.
1. MUTE Button
> Mute the Volume (Press)
> Eject disc (when disc inserted)
(Long press)
2. Volume
Increase the volume
3.
MENU Button
> Show main menu (Press)
> Power “ON” / “OFF” (Long press)
4. Volume
Decrease the volume
5. USB Connector
6. Reset
Load factory settings
7. AUX in Jack
8. Microphone (
Built in and External Microphone
)
We recommend to use External
Microphone for better Quality. Internal
Mic. is just for urgent use, in case of
External Mic. broken.
9.
HOME Button
Show main menu
MENU Button
Show MENU options
BACK Button
Back to previous MENU.
Control Button
> Touch to show / hide the Control
Buttons
> Touch and hold to move icons.
10. Map Card Slot
11. Disc Slot
Insert the disc with label side facing up.
12. Remote Sensor
* Default Path:
1. Path of USB(5): /mnt/sdcard/external_usb
2. Path of Map Card(10): /mnt/sdcard/
external_sd
The path is used for navigation. To install
a new map, please install the apk le rst,
then start the application and set the path
to "/mnt/sdcard/external_sd".
