ADB C 103 User Manual

Fresnel and PC lens Spotlights
1000, 1200 & 2000 W
Page 14
Issue 002
F 101 13° - 59° F 201 12° - 61°
Cd x 1000
2 4 6
150
200
50
100
Cd x 1000
20
12
16
10 20
4
8
30
1200W 182000 17000
13° 59°
Distance (m) Lux Ø (m) Lux Ø (m)
8 2844 1,8 266 9,0
10 1820 2,3 170 11,3
12 1264 2,7 118 13,6
14 929 3,2 87 15,8
16 711 3,7 66 18,1
18 562 4,1 52 20,4
20 455 4,6 43 22,6
1000W
1200W
Photometric Data
Typical values measured without wiremesh,
Lamp : 220V, 3200K, biplane: 1000W / 26000 lm
1200W / 30000 lm
Light Distribution (Half Beam)
Note
To convert Candelas into Lux, divide by the square of the distance (in m).
Min.Angle
Max.Angle
Min.Angle Max.Angle
Axial intensity (Cd)
Angle
Light Levels (lux) and Field Ø(m)
Cd x 1000
300
100
200
2 41 3 5 6
20
30
10
10 20 30
Cd x 1000
2000W 280000 27500
12° 61°
Lux Ø (m) Lux Ø (m)
8 4375 1,7 430 9,4
10 2800 2,1 275 11,8
12 1944 2,5 191 14,1
14 1429 2,9 140 16,5
16 1094 3,4 107 18,9
18 864 3,8 85 21,2
20 700 4,2 69 23,6
Photometric Data
Typical values measured without wiremesh
Lamp : 220V, 3200K, biplane, 2000W / 52000 lm
Light Levels (lux) and Field Ø(m)
Light Distribution (Half Beam)
Note
To convert Candelas into Lux, divide by the square of the distance (in m).
Min.Angle
Max.Angle
Min.Angle Max.Angle
Axial intensity (Cd)
Angle
Distance (m)
