L-854 Radio Control Equipment
96A0390 Rev.J
DISCLAIMER / WARRANTY
© ADB Airfield Solutions All Rights Reserved32
3.9 Spare Parts Create a sufficiently large stock of spare parts to maintain the L -854 RCE Digital Radio
Control in the field. Consider acquiring approximately 10% spare final assemblies (with a
minimum quantity of 1) for the total amount of equipment in the field. This allows for repairs to
be made in the shop. Components that are more likely to need replacement, such as PCB
subassemblies should be stocked in smaller quantities. For the unit, it is highly recommended
to have a least one entire unit as a spare, or for larger installations, at least 10% of the total
units installed.
For the L -854 unit, see the table below for spares.
• Consider acquiring 10% spares for critical components noted as (A) in the table below. If
only a small number of units are installed, consider acquiring at least 1 of each of the
components noted as (A) below.
• Also consider acquiring 1% spares for parts noted as (B) in the table below. If it is
important to have a robust level of spare parts on hand, and only a small number of units
are installed, consider acquiring 1 of each of the components noted as (B) below.
Table 14: Spare Parts
Part Number Description Location Notes Spares
44A6748 Radio Control Board Figure 2 Figure 3 A
44A6749 Radio Power Supply Board Figure 2 Figure 4 A
44A6747 Radio Relay Board (3A) Figure 2 Figure 5 A
44A6746 Radio Display Board Figure 2 Figure 7 A
45A0267 Power Switch A
45A0469 Door Interlock Switch Figure 2 A
53A0432 Relay (40A) Figure 9 Option
89A0286/12 20-pos Ribbon Cable
Figure 8,
Figure 10
B
89A0284/10 14-pos Ribbon Cable
Figure 8,
Figure 10
B
89A0285/06 16-pos Ribbon Cable
Figure 8,
Figure 10
B
44A6746 Display Assembly Figure 7 A
44A6747 Relay Assembly (3A) A
44A6748 Control Assembly A
44A6749 Power Supply Assembly A
47A0213 Fuse, .5A 5mm x 20mm SLO BLO 3 A
47A0214 Fuse, 5A 5mm x 20mm SLO BLO 3 A
53A0432 Relay (50A) Option
61A0430 Whip Antenna B
61A0429-01 Internal Antenna Mounting Kit (with cable) B
61A0447 Remote Antenna Cable (50 ft / 12.24m) Option
61A0447/100 Remote Antenna Cable (100 ft / 30.5m) Option
61A0448 Standard Remote Antenna (Rami AV-5) Option
61A0470 Heavy Duty Remote Antenna (Rami AV-1) Option
