DLP-529
Page 3 of 4
8105-B
UNIT CONFIGURATION
1. MUX Configuration
2. ODS2 Configuration
3. QLX Configuration
4. HLX Configuration
5. DLX Configuration
6. RLX Configuration
Display/Edit All MUX Configuration Parameters
Press CONTROL-A For Assistance
Figure 529-3. Unit Configuration Menu
DS3MUX CONFIGURATION
Unit Equip State : EQUIPPED
Unit Service State : OUT OF SERVICE
MUX Protect Status : UNPROTECTED
Facility Service State: OUT OF SERVICE
Transmit LBO Setting : IN
DS1 Loopback Mode : C-BIT
DS3 Framing Format Status (Display Only): M13
Press CONTROL-A For Assistance
6660-C
Figure 529-4. DS3 MUX Configuration Screen
