TRANSACTION LANGUAGE 1 (TL1) INTERFACE DESCRIPTION
Summary:
This TAD describes the commands used to operate the Soneplex Loop Extender
through a terminal using Transaction Language 1 (TL1). All operations are performed at a local
and/or remote terminal using an EIA-232 interface. For additional information on TL1 commands,
refer to the Soneplex TL1 Interface Specification Manual, listed under Related Publications at the
beginning of this manual, for more information.
Note:
The TL1 interface is case-insensitive. All input commands are mapped to
uppercase except for TID and CTAG. Size of input commands is limited to 512 bytes.
The following notational conventions are used throughout this TAD:
•
cr
— Carriage return
•
lf
— Line feed
•
^
— Blank space
•
YY-MM-DD
— Year-Month-Day
•
HH:MM:SS
— Hour:Minute:Second
•
...
— Indicates zero or more repetitions of expression contained in brackets
•
[ ]
— One or more parameters contained in brackets are optional
•
{ x }
— Selection of one and only one of the listed parameters is allowed
•
< >
— Indicate names of parameters that will be replaced by parameter
values in actual TL1 transactions
TL1 Command Syntax
Any user request is considered a command. Commands generally consist of five blocks:
<command block>:<routing block>:<access block>:<correlation block>:<data block(s)>;
The
command block
consists of commands, verbs, and modifiers separated by hyphens.
<command verb> - <modifier>[-<modifier>]
For example: The command block OPR-LPBK contains the command verb OPR (OPeRate) and
the modifier LPBK (LooPBacK) to provide for the loopback function. The command block SET-
ATTR-T1 contains the command verb SET, the modifier ATTR (ATTRibute), and the modifier
T1 to provide the mechanism for setting attributes of a T1 circuit.
