ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-100
© 2000, ADC Telecommunications, Inc.
DLP-531
Page 2 of 7
HLX CONFIGURATION
1. HLX Unit Configuration
2. Loopback Configuration
Press CONTROL-A For Assistance
6661-A
Figure 531-1. HLX Configuration Menu
9818-A
HLX UNIT CONFIGURATION
Group: 6 Slot: 1 Circuit ID:
Unit Equip State : EQUIPPED Loop Power Setting: ENABLED
Unit Service State: IS Loop 2 Operation : ENABLED
T1 Provision : YES Half AIS Feature : ENABLED
T1 Service State : OOS HDSL Service State: IS
T1 Framing Format : AUTO-UNFRAMED HDSL BER Threshold: 1E-7
T1 BER Threshold : 1E-7 HDSL SNR Threshold: +5 dB
HLXC T1 Line Code : NOT APPL HDSL PA Threshold : +33 dB
HLXC DSX-1 EQ : NOT APPL Network DS1 Source: NOT APPL
HLXR T1 Line Code : AUTO-AMI Network Keep Alive: AIS
HLXR LBO Setting : UNIT SWITCH HLXR Simplex Power: NOT APPL
DS0 Channel: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
(B = blocked) . . . . . . . . . . . . . . . . . . . . . . . .
Blocked Channel Pattern: 11111111
Remote HSKP Labels: HSKP1: RMT-HSKP1 HSKP2: RMPT-HSKP2
User Notes :
HLXC Switch Settings - DSX-1 EQ : NOT APPL Loop Power: NOT APPL
HLXR Switch Settings - Simplex Power : NOT APPL Loop 2 Op : NOT APPL
LBO : 0.0 db
Press CONTROL-A For Assistance
Figure 531-2. HLXC Unit Configuration Screen
To Next Page
