ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-117
© 2000, ADC Telecommunications, Inc.
DLP-534
Page 4 of 6
Table 534-1. RLX Configuration Fields, continued
FIELD TYPE OPTIONS DESCRIPTION DEFAULT
BER Threshold Toggle Range of 10
-3
to 10
-9
The average Bit Error Ratios of both the
incoming DS1 signals are monitored by the
RLX. By monitoring BERs, the RLX is
capable of triggering a minor alarm when
any of the monitored signals degrades
below the BER threshold level.
10
-7
Span Power Setting* Toggle UNIT SWITCH† Defaults to the span power hardware
configuration (DIP SWITCH) setting on the
Version A RLX only.
Version A only: UNIT
SWITCH
ENABLED Allows span power on the Version B RLX.
To activate this selection, its jumper must
be set to either ±130V or –130V as shown
in Figure 525-2 or
Figure 525-3.
Version B only:
ENABLED
DISABLED Stops span power on the Version B RLX.
Pulse Equalization* Fixed Locked at NOT APPL.
LBO Setting*† Toggle UNIT SWITCH Defaults to the hardware configuration (DIP
SWITCH) LBO setting on the Version A
RLX.
Version A only: UNIT
SWITCH
0.0 dB, 7.5 dB, 15.0
dB, or 22.5 dB
Version A only: Overrides the hardware
configuration (DIP SWITCH) setting. Sets
the LBO in decibels.
Version B only: Sets the LBO in decibels.
Version B only: 0.0 dB
Programmable
Loopback
Toggle ENABLED Enables response to programmable
loopback codes and overrides hardware
configuration settings.
DISABLED
DISABLED Disables response to programmable
loopback codes and overrides hardware
configuration settings.
*Note: Unit switch settings (Pulse Equalization, Span Power, NID, and LBO) are shown on the bottom of the configuration screen.
†Note: The UNIT SWITCH option appears on screen for both RLX types, but is only functional for Version A.
(continued)
