Table 534-1. RLX Configuration Fields, continued
FIELD TYPE OPTIONS DESCRIPTION DEFAULT
DS0 Channel Toggle “B” (for DS0 Channel
blocking) or blank (for
normal operation) for
each of the 24 DS0
channels.
Version A: blocking a channel causes all 1s
pattern to be transmitted in both directions
on the channel.
Version B: blocking a channel causes the
blocking pattern (FFhex or 7Fhex) set up
via the onboard jumper to be transmitted in
both directions.
Blank
T1 Service State Toggle IS (In-Service) Places facility in service and allows T1
alarm reporting by the MPU.
OOS
OOS (Out-Of-Service) Removes facility from service and stops
alarm reporting by the MPU.
