High Speed Loopback Status/Commands
Unit Location - LOCAL
===========
COMMANDS:
Loopback :
STATUS:
Unit Type: DS3MUX
+---------+
| |
----------------->|-------->|----------------->
| |
NETWORK DS3 | | DEMUX
| |
<-----------------|<--------|<-----------------
|fac term|
+---------+
Press CONTROL-A For Assistance
6665-C
DS3 MUX LOOPBACK
SELECTION FIELD
Note: Do not perform a DS3 loopback when the Soneplex Broadband chassis
is connected to a DS3 CAM unit in the Soneplex CCAS system.
Figure 541-3. High Speed (DS3 MUX) Loopback Status/Commands Screen
11379-A
Low Speed Loopback Status/Commands
Group: 1 DS1#: 4
COMMANDS:
Loopback:
STATUS:
Unit Type: HLXC HRX1 HLXR
Unit Location - LOCAL REPEATER REMOTE
=========== =========== ===========
+---------+ +---------+ +---------+
| | | | | |
-------------->|-------->|-------->|-------->|-------->|-------->|------------->
NETWORK | | | | | | CUSTOMER
DS1 | | HDSL | | HDSL | | DS1
| | | | | |
<--------------|<--------|<--------|<--------|<--------|<--------|<-------------
|net cust| |net cust| |net cust|
+---------+ +---------+ +---------+
Programmable Loopback Armed State: ARMING DISABLED
Press CONTROL-A For Assistance
HLXC LOOPBACK
SELECTION FIELD
HLXR LOOPBACK
SELECTION FIELD
SELECTION FIELD
HRX LOOPBACK
Figure 541-4. Low Speed Loopback Status/Commands Screen
