ADC Soneplex Broadband System - Page 159

ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-136
© 2000, ADC Telecommunications, Inc.
DLP-541
Page 7 of 16
High Speed Loopback Status/Commands
Unit Location - LOCAL
===========
COMMANDS:
Loopback : ACT NET
STATUS:
Unit Type: DS3MUX
+---------+
| |
----------------->|----+ |----------------->
| | |
NETWORK DS3 | | | DEMUX
| | |
<-----------------|<---+ |<-----------------
|fac term|
+---------+
Press CONTROL-A For Assistance
6666-C
Note: Do not perform a DS3 loopback when the Soneplex Broadband chassis
is connected to a DS3 CAM unit in the Soneplex CCAS system.
Figure 541-5. DS3 MUX Network Loopback Screen
11381-A
Low Speed Loopback Status/Commands
Group: 4 DS1#: 1
Unit Location - LOCAL REPEATER REMOTE
========== ========== ==========
COMMANDS:
Loopback: N/A
STATUS:
Unit Type: HLXC NONE HLXR
+---------+ +---------+
| | | |
-------------->|--+ +->|---------------------------->|---------|------------->
NETWORK | | | | | | CUSTOMER
DS1 | | | | HDSL | | DS1
| | | | | |
<--------------|<-+ +--|<----------------------------|<--------|<-------------
|net cust| |net cust|
+---------+ +---------+
Programmable Loopback Armed State: ARMING DISABLED
Press CONTROL-A For Assistance
Figure 541-6a. HLXC Customer Loopback Screen
