Low Speed Loopback Status/Commands
Group: 4 DS1#: 1
Unit Location - LOCAL REPEATER REMOTE
========== ========== ==========
COMMANDS: N/A
Loopback:
STATUS:
Unit Type: HLXC NONE HLXR
+---------+ +---------+
| | | |
-------------->|-------->|---------------------------->|--+ +->|------------->
NETWORK | | | | | | CUSTOMER
DS1 | | HDSL | | | | DS1
| | | | | |
<--------------|<--------|<----------------------------|<-+ +--|<-------------
|net cust| |net cust|
+---------+ +---------+
Programmable Loopback Armed State: ARMING DISABLED
Press CONTROL-A For Assistance
Figure 541-7a. HLXR Customer Loopback Screen
9491-D
Low Speed Loopback Status/Commands
Group: 6 DS1#: 1
Unit Location - LOCAL REPEATER REMOTE
========== ========== ==========
COMMANDS:
Loopback: N/A
STATUS:
Unit Type: HLXC NONE HLXR
+---------+ +---------+
| | | |AIS
-------------->|-------->|---------------------------->|--+ +->|------------->
NETWORK | | | | | | CUSTOMER
DS1 | | HDSL | | | | DS1
| | | | | |
<--------------|<--------|<----------------------------|<-+ +--|<-------------
|net cust| |net cust|
+---------+ +---------+
Programmable Loopback Armed State: ARMING DISABLED
Press CONTROL-A For Assistance
Figure 541-7b. HLXR Network Loopback Screen
