ADC Soneplex Broadband System - Page 164

ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-141
© 2000, ADC Telecommunications, Inc.
DLP-541
Page 12 of 16
9698-A
Low Speed Loopback Status/Commands
Group: 2 DS1#: 1
Unit Location - LOCAL REPEATER REMOTE
======== ========= ========
COMMANDS:
Loopback: N/A
STATUS:
Unit Type: ODS2 NONE QLX
+---------+ +---------+
|| | |
---------------> | --+ +-> |-------------------------> |-------->|--------------->
NETWORK | | | | | CUSTOMER
DS1 | | | | | DS1
| || | |
<--------------- | <-+ +-- |<------------------------- |<--------|<---------------
|net cust | |net cust |
+---------+ +---------+
Press CONTROL-A For Assistance
Figure 541-10a. ODS2 Customer Loopback
9496-C
Low Speed Loopback Status/Commands
Group: 2 DS1#: 1
Unit Location - LOCAL REPEATER REMOTE
========== ========== ==========
COMMANDS:
Loopback: N/A
STATUS:
Unit Type: ODS2 NONE QLX
+---------+ +---------+
| | | |
-------------->|-------->|---------------------------->|--+ +->|------------->
NETWORK | | | | | CUSTOMER
DS1 | | | | | DS1
| | | | |
<--------------|<--------|<----------------------------|<-+ +--|<-------------
|net cust| |net cust|
+---------+ +---------+
Press CONTROL-A For Assistance
AIS
OPTICAL DS2
Figure 541-10b. Remote QLX Network Loopback Screen
