ADC Soneplex Broadband System - Page 235

ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-212
© 2000, ADC Telecommunications, Inc.
DLP-570
Page 2 of 18
RTAU
STATUS
LINE CODE
INTRUSIVE
TEST
D
S
1
RX
TX
12693-A
BIPOLAR
ACCESS
B8ZS
AMI
Figure 570-1. RTAU Front Panel
5323-A
SYSTEM MAINTENANCE
1. Force/APS Commands
2. Reset/LED Test Commands
3. Execute ACO (Alarm Cut-Off)
4. Loopback Status/Commands
5. Display Inventory
6. Display Circuit IDs
7. Upload/Download Commands
8. Test Access Unit Commands
Press CONTROL-A For Assistance
Figure 570-2. System Maintenance Menu
