ADC Soneplex Broadband System - Page 268

ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-245
© 2000, ADC Telecommunications, Inc.
DLP-576
Page 2 of 2
10387-A
ALL OTHER
CHASSIS
(NO STRAP)
LAST
CHASSIS
IN CHAIN
BERG JUMPER
JD 13
Note: The default setting is “strapped”.
Figure 576-1. Berg Jumper Configuration on MPU for TBOS Linking
CHASSIS #1
CHASSIS #4
10392-A
+ –
RX
+ –
TX
PORT 4
PORT 1
+ –
RX
+ –
TX
PORT 4
PORT 1
.
.
.
Figure 576-2. Daisy-Chaining Chassis for TBOS Linking
