ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-254
© 2000, ADC Telecommunications, Inc.
TAD-101
Page 6 of 9
Table 101-1. Soneplex Broadband System (V5) Specifications, continued
PARAMETER SPECIFICATION REMARKS
RTAU Module
DS1 Jack Access Jack Type Bantam
Electrical Interface Bipolar
Impedance 100 ohms nominal
±
5%
Line Code AMI or B8ZS Controlled by front panel switch
Line Rate 1.544 Mbps ± 130 ppm max.
Interface Connections
Alarm 0.045 inch wire wrap post
Optical DS2 FC or SC Per catalog number.
DS3 Input 75 ohm BNC
HDSL/DS1 0.045 inch wire wrap post
MPU (Front Port)
Craft Interface DB-25 D subminiature Craft, TL1 (EIA-232)
Serial Ports
Port 1 0.045 inch wire wrap post TBOS (EIA-422)
Port 2 DB-25 D subminiature TBOS, Craft, TL1 (EIA-232)
Port 3 DB-25 D subminiature Craft, TL1, TL1 (X.25) (EIA-232)
