ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-256
© 2000, ADC Telecommunications, Inc.
TAD-101
Page 8 of 9
Table 101-5. Broadband Power Characteristics Version D and later HLXCs
HLXR
CONFIGURATION
# OF HRXS IN
SYSTEM
# OF HLXCS IN
CHASSIS
MAX. POWER
CONSUMPTION
MAX. POWER
DISSIPATION
MAX. CURRENT DRAIN
(AT –48 VDC)
Span Power ON;
DS1 simplex
disabled; D2A, D4,
D4A, D4B,
Version E HLXRs
0 1 10.5 watts 6.5 watts 219 mA
28 322 watts 210 watts 6.7 amps
1 1 21.5 watts 8.5 watts 448 mA
28 630 watts 266 watts 13.1 amps
2 (Version
E HLXR
only)
1 25.5 watts 8.5 watts 531 mA
28 742 watts 266 watts 15.4 amps
Span Power ON;
DS1 simplex
enabled; D1, D2,
D2A-SP, D3, D3A,
D3B HLXRs
0 1 19.0 watts 7.5 watts 396 mA
28 560 watts 238 watts 11.7 amps
1 1 28.0 watts 9.5 watts 583 mA
28 812 watts 294 watts 16.9 amps
Span Power ON;
Local power at
remote; D1 HLXR
0 1 5.5 watts 5.5 watts 115 mA
28 182 watts 182 watts 3.8 amps
1 1 14.0 watts 7.0 watts 292 mA
28 420 watts 224 watts 8.8 amps
Span Power OFF;
Local power at
remote; D1 HLXR
0 1 5.5 watts 5.5 watts 115 mA
28 182 watts 182 watts 3.8 amps
1 No power values because HRXs require span power.
Note: Power values for a fully configured chassis (28 HLXCs) include the power of the common equipment:
APU (7.5 watts), MPU (5 watts), and two DS3 MUX modules (8 watts each), for a total of 28 watts.
