ADC Soneplex Broadband System - Page 313

ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-290
© 2000, ADC Telecommunications, Inc.
TAP-101
Page 4 of 13
6675-B
ACTIVE ALARMS
Legend:
Access ID=Identifier[-]Shelf-Grp-Slot[-Site(1=Lcl,2=Rmt) | -Loop(1=Lp 1,2=Lp 2)]
Access ID Locn Circuit ID Condition Status ACO
---------------- ---- -------------------- ---------------- ------ ---
T2-1-3-1 NEND OPTICAL LOS MJ NO
T2-1-3-1 NEND OPTICAL LOF MJ NO
T1-7-1-1 FEND AIS MN NO
T1-7-1-2 FEND LOF MJ NO
HDSL-1-7-1-1 NEND T-BERP MN NO
HDSL-1-7-1-1 NEND T-SNR EV NO
HDSL-1-7-1-1 FEND LOF MJ NO
HDSL-1-7-1-1 FEND T-BERP MN NO
HDSL-1-7-1-1 FEND T-SNR EV NO
HDSL-1-7-1-2 NEND RECOVERY MN NO
HDSL-1-7-1-2 NEND LOF MJ NO
HDSL-1-7-1-2 NEND T-BERP MN NO
HDSL-1-7-1-2 NEND T-SNR EV NO
HDSL-1-7-1-2 FEND LOF MJ NO
HDSL-1-7-1-2 FEND T-BERP MN NO
HDSL-1-7-1-2 FEND T-SNR EV NO
Page 1 of 1 Press CONTROL-A for assistance
Figure 101-1. Active Alarms Screen (MPU V5.1) (Sample)
11376-A
ACTIVE ALARMS
Legend:
Access ID=Identifier[-]Shelf-Grp-Slot[-Site(1=Lcl,2=Rmt) | -Loop(1=Lp 1,2=Lp 2)]
Page 1 of 1 Press CONTROL-A for assistance
Access ID Locn Circuit ID Condition Status ACO
---------------- ---- -------------------- ---------------- ------ ---
EQPT-1-3-1 GRP 2 MISMATCH MN NO
T2-1-3-1 NEND OPTICAL LOF MJ NO
T1-1-1-4-1 NEND AIS EV
T1-1-1-4-2 NEND LOS MJ NO
T1-1-7-1-2 CRP1 NET LOOPED BACK EV NO
EQPT-LIU1-2-1-2 HLXR INCOMPATIBLE MN NO
HDSL-1-7-1-1 NEND T-SNR EV NO
HDSL-1-7-1-1 FEND LOF MJ NO
HDSL-1-7-1-1 FEND T-BERP MN NO
HDSL-1-7-1-1 FEND T-SNR EV NO
HDSL-1-7-1-2 NEND RECOVERY MN NO
HDSL-1-7-1-2 NEND LOF MJ NO
HDSL-1-7-1-2 NEND T-BERP MN NO
HDSL-1-7-1-2 NEND T-SNR EV NO
HDSL-1-7-1-2 FEND LOF MJ NO
HDSL-1-7-1-2 FEND T-BERP MN NO
HDSL-1-7-1-2 FEND T-SNR EV NO
Figure 101-2. Active Alarms Screen (MPU V5.2) (Sample)
