TAP-104
Page 3 of 3
Table 104-1. Dual Repeater Compatibility Indicators
UNIT TYPE INCOMPATIBILITY CORRUPTED
HLXC* HRX1** HRX2** HRX3 HLXR*** INDICATOR SERIAL NUMBER
NO INCOMPATIBILITIES
New -- -- -- New None None
New -- -- -- Old None None
Old -- -- -- New None None
New New -- -- New None None
Old New -- -- New None None
New Old -- -- New None None
New New -- -- Old None None
Old Old -- -- New None None
Old New -- -- Old None None
New Old -- -- Old None None
New New New -- New None None
SINGLE INCOMPATIBILITIES
Old New New -- New HLXR 2ND-HRX1-IN
†
New Old New -- New HRX1 OLD-HRX1-IN
†
New New Old -- New HRX2 OLD-HRX2-IN
†
New New New -- Old HLXR 2ND-HRX1-IN
†
New New New Old/New New HLXR 3RD-HRX2-IN
†
UNDETECTABLE INCOMPATIBILITIES
Old Old Old/New Any Old/New Undetectable Not Shown
Old/New Old Old Any Old/New Undetectable Not Shown
* “New” HLXC refers to the Version E HLXC; “Old” HLXC refers to the Version D (or earlier) HLXC.
** “New” HRX refers to the Version B HRX; “Old” HRX refers to the Version A HRX.
*** “New” HLXR refers to the Version E HLXR; “Old” HLXR refers to the Version D (or earlier) HLXR.
†
The corrupted serial numbers shown in these examples will appear in the Craft Interface’s
Inventory Status screen if the incompatibility is present.
