ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
2-41
© 2000, ADC Telecommunications, Inc.
DLP-506
Page 5 of 5
RECEIVE
CONNECTOR
TRANSMIT
CONNECTOR
2170-A
Figure 506-2. ODS2 Transmit and Receive Connector Locations
