ADDAC System ADDAC207 - Non-Volatile Memory; Tech Specs

ADDAC SYSTEM page 31
TECH SPECS
MECHANICAL:
Format: Eurorack
Width: 10 HP
Depth: 6 cm
CONTROL VOLTAGE I/O:
CV inputs: ± 5v
Assign input: + 5v
CV outputs: 0 +10v
ELECTRICAL:
Max current: 150mA
Bus Board Cable: 8 × 2 IDC (Doepfer style) connector
Non-Volatile MEMORY
There are two different locations in memory:
- Main Memory, stores overall settings
- Presets Memory, stores 11 User Presets
NOTE 3
NOTE 4
QUANTIZING TYPE
GATE LENGTH
TRIGGER RESET
OCTAVE OFFSET
Scale Temperament
Gate Off Condition
CV Assigns
NOTE 2
Scale Notes
WHAT’S KEPT IN PRESETS MEMORY
WHAT’S KEPT IN MAIN MEMORY
Fine Tunings
Moog/Buchla
Reaction Time
ADDAC207 INTUITIVE QUANTIZER USER’S GUIDE
April.2021Revision.05
