Additel 927 - Page 10

07
③ Use a 24 mm wrench to remove the lock nut and rotate the high pressure piston lead screw manually until it can be pulled out. Please
refer to picture 2.2.2.
④ Please refer to picture 2.2.3 to exchange all the damaged parts.
3. High-pressure and
fine adjustment handle
12
5. High-pressure
piston lead screw
4. Lock nut
Picture.2.2.1 Picture.2.2.2
5. High-pressure
piston lead screw
8. Axle sleeve 76
Picture.2.2.3
