Dimensions for Mounting sMI6 Module

Adept SmartMotion Installation Guide, Rev. B 49

Figure 4-4. Table Mounting

4X 40356-00001

378.6

29.5

16.0

14.3

4X M3 x 6MM

BOTH SIDES

R 3.6

21.6

24.1

391.8

121.0

12.1

24.9

1.9
